This product is customizable, making it suitable for different types of machinery and equipment. It is designed to be sensitive to changes in weight and has a sensitivity of 2.0±0.2 MV/V. This means that it can detect even small changes in weight, making it ideal for applications that require precise measurements.
The Single Point Load Cell is also designed to compensate for temperature changes. It can operate in temperatures ranging from -10°C to +40°C, ensuring accurate measurements even in harsh environments. This makes it ideal for use in applications where temperature fluctuations are common.
The cable specification for this product is φ5, which means that it has a diameter of 5mm. This makes it easy to connect to different types of machinery and equipment without compromising on performance.
The Single Point Load Cell is a parallel beam load cell, meaning that it is designed to measure weight in a single direction. This makes it ideal for use in applications where weight is applied in a single direction, such as in vending machines and platform scales.
In summary, the Single Point Load Cell is a highly accurate weight measurement transducer that is customizable and suitable for use in various applications. It is designed to compensate for temperature changes, has a cable specification of φ5, and is a parallel beam load cell. It is ideal for use in vending machines, platform scales, and other applications that require precise weight measurements.
| Model | SPA-01 |
| Protection Class | IP65 |
| Customized | Acceptable |
| Accuracy | 0.02%FS |
| Material | Aluminum Alloy |
| Input Resistance | 400±10Ω |
| Temp | -20-60°C |
| Compensated Temperature | -10°C To +40°C |
| Usage | Weight Measurement Transducer |
| Power Supply | 10V DC |
The SPA-01 load cell is widely used in various weighing systems for its excellent stability and accuracy. Here are some of the product application occasions and scenarios:
In conclusion, Top Sensor SPA-01 Single Point Type Load Cell is an excellent choice for high-precision and stable weighing applications. Its parallel beam load cell design and high accuracy make it suitable for a wide range of industries and scenarios.
Top Sensor SPA-01 Single Point Load Cell is a high precision aluminum alloy based force sensor. This load cell is ideal for Vending Machine Load Cell applications due to its high accuracy of 0.02%FS. It is a parallel beam load cell designed to provide reliable and accurate measurements in environments with temperatures ranging from -20°C to +60°C. The load cell comes with a cable specification of φ5 and requires a power supply of 10V DC.
At Top Sensor, we understand that every application is unique and requires customization to meet specific requirements. We offer product customization services to our customers, enabling them to tailor the SPA-01 Single Point Load Cell to their specific needs. Our team of experts will work with you to ensure that the load cell meets your requirements in terms of accuracy, cable length, connector type, and other specifications.
Top Sensor SPA-01 Single Point Load Cell is manufactured in China and is built to the highest standards of quality and reliability. Contact us today to learn more about our Vending Machine Load Cell and other product customization services.
Product Packaging: This single point load cell will be packaged securely in a cardboard box with appropriate padding to ensure safe transportation. The load cell will be placed in a plastic bag to avoid any damage from moisture or dust during transit. Shipping: We offer free shipping for this product within the United States. The product will be shipped within 3-5 business days of receiving the order. Delivery times may vary depending on the destination, but typically take 5-7 business days for domestic orders. For international orders, shipping rates and delivery times will vary based on the destination and shipping method selected during checkout.
