The SPA-02JM Single Point Type Load Cell features a φ5 cable specification and requires a 10V DC power supply. With an input resistance of 400±10Ω, this load cell provides excellent sensitivity and can measure even the slightest of weights with precision.
Constructed with durable materials, the SPA-01 load cell is built to withstand harsh environments and is protected with an IP65 protection class rating. This makes it suitable for use in a variety of industrial, commercial and scientific applications.
With its compact design, the SPA-01 Single Point Type Load Cell can be easily integrated into your weighing system, providing a high level of accuracy and dependability.
Whether you need to weigh small items or large loads, the SPA-01 Single Point Type Load Cell is the perfect choice to ensure accurate measurements. So, if you're looking for a reliable and high-quality load cell for your weighing application, look no further than the SPA-01 Single Point Type Load Cell.
| Product Attribute | Specification |
| Type | Single Point Type Load Cell |
| Material | Alloy Aluminum Load Cell |
| Sensitivity | 2.0±0.2 MV/V |
| Accuracy | 0.02%FS |
| Cable Length | 2-3 Meters |
| Cable Specification | φ5 |
| Power Supply | 10V DC |
| Compensated Temperature | -10°C To +40°C |
| Operating Temperature | -20°C To +60°C |
| Customized | Acceptable |
The SPA-01 load cell is designed to provide accurate and precise weight measurement with an accuracy of 0.02%FS. Additionally, it has an input resistance of 400±10Ω which makes it highly sensitive to changes in weight. The load cell operates effectively within a temperature range of -20°C to +60°C, making it suitable for use in different environments.
The load cell comes with a cable specification of φ5 which makes it easy to connect to other weighing equipment. It can be used in various applications such as weighing of raw materials in food processing industries, weighing of products in packaging industries, and monitoring of inventory in warehouses.
The SPA-01 load cell is also useful in automotive industries to measure the weight of vehicles and their components. It can be used to weigh trucks, trailers, and other heavy-duty vehicles to ensure compliance with weight restrictions. The load cell is easy to install and maintain, and it comes with a user manual that provides all the necessary information to operate it.
In summary, the Top Sensor SPA-01 Single Point Type Load Cell is an excellent choice for anyone looking for an accurate and reliable weighing transducer. It is suitable for use in various scenarios and can be applied in different industries. Its durability, precision, and ease of use make it a popular choice among many businesses.
Top Sensor SPA-01 Single Point Load Cell is a Parallel Beam Load Cell made of Alloy Aluminum, designed for weight measurement transducer applications. It has a Protection Class of IP65, making it suitable for harsh industrial environments. The load cell comes with a standard cable length of 2-3 meters and a φ5, 2m cable. Top Sensor also offers customized solutions to meet specific customer requirements.
Product Packaging:
The single point load cell will be packaged in a sturdy cardboard box to ensure safe transportation and delivery. The load cell will be wrapped in bubble wrap to prevent any damage during transit.
Shipping:
The product will be shipped via a reputable courier service to the address provided by the customer. The shipping cost will depend on the destination and will be calculated at the time of checkout. The estimated delivery time will be provided to the customer at the time of purchase.
