Dimensions: (mm)
Wire Connection:
Parameters:
Precision: |
C2 |
||
Rated Output: |
2mv/v±0.003 |
||
Creep(%F.S/30min): |
±0.02 |
||
Zero balance(%F.S): |
±1.5 |
||
Input resistance: |
700±5 |
||
Output resistance: |
700±5 |
||
Insulation resistance: |
≥5000(100VDC) |
||
Temp.effect on span(%F.S/10℃): |
±0.017 |
||
Temp.effect on zero(%F.S/10℃): |
±0.02 |
||
Use temp.range(℃ ): |
-20~+55 |
||
Excitation voltage(V): |
9~12(DC) |
||
Safety overload (%F.S) |
150% |
||
Ultimate overload (%F.S) |
200% |
||
Defend grade |
IP68 |
||
Cable Length: |
5 meters -15 meters |
