Dimensions:(mm)
SPECIFICATION |
|||
Precision: |
0.05% FS |
||
Rated Output: |
2.0 ±0.1 |
||
Creep(%F.S/30min): |
±0.1 |
||
Zero balance(%F.S): |
±1.0 |
||
Input resistance: |
1000±10 |
||
Output resistance: |
1000±10 |
||
Insulation resistance: |
≥5000(100VDC) |
||
Temp. effect on span(%F.S/10℃): |
±0.05 |
||
Temp. effect on zero(%F.S/10℃): |
±0.05 |
||
Use temp. range(℃): |
-20~+55 |
||
Excitation voltage(V): |
9~12(DC) |
||
Safety overload (%F.S) |
150% |
||
Ultimate overload (%F.S) |
200% |
||
Defend grade |
IP66 |
||
Cable Length: |
220 -660 mm |
||
Wire Connection Method |
|||
RED=Input+ |
BLACK=Input- |
GREEN=Output+ |
WHITE=Output- |
