The Foil Strain Gauge is designed to be customized according to the needs of the user. This makes it a versatile product that can be used in a wide range of industries. It is commonly used in the automotive, aerospace, and construction industries to measure the strain that an object undergoes due to external forces.
The Foil Strain Gauge works by measuring the change in electrical resistance that occurs when a material undergoes strain. It does this by using a metallic foil that is attached to the carrier material. When the material undergoes strain, the metallic foil also undergoes strain which causes a change in its electrical resistance. This change in resistance is then measured by the gauge and converted into a strain measurement.
The Foil Strain Gauge has a measurement range of 0-1000 microstrain which makes it suitable for measuring small amounts of strain. It is also highly accurate which makes it ideal for use in applications where precision is important.
The Half Bridge Strain Gauges are commonly used in applications where only one axis of strain needs to be measured. They are ideal for measuring the strain that occurs in materials such as beams and columns. The Foil Strain Gauge is a type of Half Bridge Strain Gauges that is easy to use and provides accurate measurements.
In conclusion, the Foil Strain Gauge is a highly versatile product that can be customized to suit the needs of the user. It is small in size, highly accurate, and can be used in a wide range of industries. The Half Bridge Strain Gauges are commonly used in applications where only one axis of strain needs to be measured, and the Foil Strain Gauge is an excellent example of this type of gauge.
| Technical Parameters | Values |
|---|---|
| Usage | Load Cell Sensor |
| Measurement Range | 0-1000 Microstrain |
| Dimensions | 5 Mm X 5 Mm |
| Material | Steel or Alloy Aluminum |
| Feature | Micro Pressure Sensor |
| Operational Temperature | -20～+80℃ |
| Hysteresis | ±0.05% Full Scale |
| Strain Gage Type | Single Element |
| Carrier Material | Phenolic Aldehyde/ Polyimide/ Epoxy |
| Service | Custom |
| Strain Gauges | Half Bridge Strain Gauges |
The BF model of Top Sensor's Foil Strain Gauges is a single element strain gauge made from high-quality steel or alloy aluminum. The silicon element is 4.7×0.22×0.02, ensuring accurate and reliable readings.
One of the main applications for this product is in load cells used for weighing and force measurement. Top Sensor's Foil Strain Gauges can be used to measure the strain on the load cell caused by the weight or force applied to it.
The BF model is also suitable for use in other types of strain gauge applications. It can be used in full bridge strain gauge configurations, making it ideal for applications such as pressure sensors and torque sensors.
Top Sensor offers custom services for their Foil Strain Gauges, allowing for tailor-made solutions to meet specific application requirements.
The BF model is manufactured in China, ensuring high-quality production standards at an affordable price point.
Overall, Top Sensor's BF Foil Strain Gauges are a versatile and reliable solution for a range of strain gauge applications, from load cells to pressure sensors and beyond.
